Handheld. Smarter.
The ZeeGee is an innovative three axis zero gravity head specifically for the handheld look. It provides freedom of movement in the pan, tilt, and unlike similar products, the roll axis, replicating the look and feel of handheld operation combined with the stability, boom range, and weight displacement of the Steadicam arm. This combination offers operators, DP's and directors a unique look that's unmistakably handheld without the shake, limited range, and operator fatigue that comes with standard handheld operation, especially when doing multiple takes.
Handheld. Smarter.
The ZeeGee combines the handheld look with everything we love about Steadicam: including added boom range, elimination of footsteps, and reduced fatigue.
Hard-Mounted
Versatility
The ZeeGee offers the choice of hard-mounted options to achieve an "undeniably hand-held" look on dollies, stands or even being suspended.
The ZeeGee:
-
Creates complete axial motion isolation
-
Control in pan, tilt, and roll
-
Small to large camera builds
-
Quick on the fly balancing and CG adjustments
-
Separate drop rates for tilt and roll
-
Adjustable fluid dampened tilt
-
Mounts on all Steadicam arm posts and 5/8" baby pin
-
Get Steadicam rentals on handheld shoots
Instantly Switch
from Steadicam arm to tripod, dolly, undersling rig or any 5/8" pin
Designed by a Steadicam operator
for Steadicam operators
Versatile!
The head can be underslung from Steadicam arms, usually from a Garfield mount, and with the "shovel handle" adapter, from ropes or elastic lines including the Cinema Devices Undersling, from cranes, speedrail rigs, or Easyrig overhead supports. Operators can independently set the drop rate CG of the roll axis independent of the tilt.
Video Gallery
Benefits
Increase Your Steadicam Rentals
ZeeGee Webminar
Watch B&H's Introduction to ZeeGee Webminar
Take the ZeeGee for a Spin
What The Experts Say
Dave Emmerichs, SOC
"The ZeeGee is simple and intuitive to operate. If you’re already an experienced Steadicam Operator, you’re going to love this thing.
I wish I’d had this device at the beginning of my career."
Neal Bryant, SOC
"Now I can get my Steadicam rate and rental on a handheld show when I otherwise wouldn't.
The ZeeGee basically paid for my wedding."
Colin Hudson, SOC
"With this I can get the camera anywhere I want and it’s half the weight of the full Steadicam. I can hold it a lot longer and still get the camera where it needs to be."
Specifications
ZeeGee
Camera payload: | Up to 70 lbs. |
Pan: | 360° |
Tilt: | 60° - 90° (based on camera length) |
Roll: | 22° from center |
Mounting: | 5/8” (PRO), 3/4” (Tiffen) arm posts with adapter sleeve or any 5/8" pin |
Locking Brakes: | Pan |
Center Position Locking Plunger: | Roll & tilt |
Variable fluid drag and brake: | On tilt |
Drop rate adjustment: | On the fly, independent CG drop rate adjustment |
Cradle and pan base: | Invertable with docking station |
Handle Grips: | Re-orientable |
Handles: | Removable & interchangable with knobs included |
Dimensions: | 19.5”x 18”x 9” |
Weight: | 11 .3 lbs/5.1 kg |
Warrantee: | 2 years |
Docking Station
Dimensions: | 20.5”x 5.5” |
Weight: | 5.3 lbs./2.4 kg |
Cradle & pan base: | Can be docked in inverted position |
-
What size Ergorig CenterFit should I get?Measure from your front hip point to the top middle of your shoulder. If the distance is less than 20 inches (50 cm) - order a Short size. If the distance is more than 20 inches (50 cm) - order a Tall size. Your front hip point is the part that feels like the tip of the triangle in your hip on the front side that is right around your belt line.
-
What size Ergorig Classic should I get?Measure from your front hip point to the top middle of your shoulder. If the distance more than 20 inches (50 cm) - order a Tall size. If the distance less than 20 inches (50 cm) - order a Short size. Your front hip point is the part that feels like the tip of the triangle in your hip on the front side that is right around your belt line.
-
Does the Ergorig work well for female operators?Works great! Most women prefer to adjust the midriff strap either above or below their chest line, and some prefer it to sit straight across. In addition to the original model, we have introduced the Ergorig CenterFit which many female operators find more comfortable.
-
Is the Ergorig CenterFit only for women?We designed the CenterFit model at the request of female operators that felt that the Classic Ergorig could have been more comfortable to their physique. To that end, the CenterFit puts the front load bearing plates in line with the sternum therefore creating no uneven pressure on the chest. Some male operators use the Ergorig CenterFit as well, but the majority of CenterFits have been purchased by female operators.
-
Do you offer Ergorig rentals?We do not rent the Ergorig directly, but work with a series of rental houses. You can find a list here.
-
I own an Ergorig Classic, can I upgrade it to a CenterFit model?Yes. Absolutely! Your Ergorig can be transformed with our "Ergorig CF Upgrade Kit" which comes with everything you need. Just turn a few knobs, bolts and screws then replace the plates and voila! To purchase an CenterFit upgrade kit click here.
-
Do you ship internationally?Yes, shipping charges can be seen in your cart, and you are responsible for any local taxes or tariffs. If you'd like to be informed when we have dealers able to sell locally in your country, please email us.
-
What's your return policy?We know you'll love it but if not, no worries. Return it within 14 days for a full refund, just pay for return shipping.
-
What's the warranty?Built to military specifications. Workmanship guaranteed for two years.
